QCXD11 INSIGHTqc™ CORDLESS CONTROLLER D TYPE

Ingersoll Rand QCXD11 is the INSIGHTqcx™ Cordless Controller (Display, Standard type) with standard software and hardware, engineered for simplified control and programming of QX Series cordless precision fastening tools in quality-critical assembly environments. This compact 24V model features a 7-inch touchscreen display, intuitive web-based interface, and robust connectivity for real-time data traceability, error-proofing, and seamless integration into production lines without requiring PC software or licenses, optimizing productivity and reducing downtime globally.

• Model: QCXD11 (Cordless Controller with display, Standard software/hardware)
• Type: Single/Multi-Tool Controller (MTC) for up to 6 QXX tools or 10 QXW tools; backwards compatible with INSIGHTqcx and QX tools
• Display: 7-inch full-color touch screen LCD with intuitive visual programming interface and embedded context-specific help
• Power Requirements: 24V DC / 2A input
• Weight: 2.5 kg (5.5 lb.)
• Dimensions/Volume: 7.5 dm³; integrated wall mount and carrying handle
• IP Rating: IP52 (when mounted vertically)
• Boot Time: 40 seconds
• Connectivity: Ethernet (1x 10/100, 1x 10/100/1000); 4x USB 2.0 ports; Wireless (Bluetooth, Zigbee 802.15.4, dual-band Wi-Fi 2.4/5 GHz); Digital I/O; EOR data out; wireless energy scan for easy pairing (up to 6 tools)
• Compatibility: All QX Connect Series tools (QXF, QXB, QXX pistol/straight, QXW Limitless, QX ETS ergonomic, QXM torque multipliers); supports Zigbee/Bluetooth/USB/Wi-Fi programming; INSIGHT Connect app integration
• Programmable Configurations: Up to 256 JOBS; 32 PSETs per tool; 8 steps per PSET; tightening strategies (torque, angle, hybrid, speed control, gang count, prevailing torque compensation, tubenut modes); quick/advanced modes; barcode scanning (USB/serial/Ethernet/manual entry); logic rules for job sequencing; multi-language support (English, French, German, Italian, Spanish, Czech, Russian, Portuguese, Polish, Simplified Chinese)
• Control System: Web-based programming via any browser (no PC/license required); unrestricted remote access from smartphones/tablets/computers; tool calibration; firmware updates; multiple user logins (unlimited, configurable)
• Data Storage: 500,000 tightening results; 500,000 tightening traces/curves; Audit log (50,000); Event log (10,000); System log (10,000); removable SSD for full backup/restore (via USB or swap)
• Operator Feedback: Real-time cycle/JOB results; system indicators (factory/wireless/link/fault status); statistics summary/alarms; SPC metrics (mean, capability Cp/Cpk, pass/fail %, mean shift, range, σ, PP/PPK); preventative maintenance alarms; onboard diagnostics (tools, wireless, digital I/O)
• Maintenance Features: Full factory reset; network discovery; IP/digital I/O settings; email alerts for statistics/maintenance (IT setup required); advanced troubleshooting via diagnostics
• Additional Features: Plug-and-play accessories/protocols; reduces hardware footprint by up to 40%; whiteboard/QR code for setup; cybersecurity authentication; no-trace transfer for some protocols (e.g., ToolsNet); MTC software upgradeable for tool consolidation and line rebalancing
