CP-77MF Compact Headlight Headlight, Brightness 400 LM, Run Time 5.5 Hours, Battery Li-poly 3.7V 1200mAh

Gentos CP-77MF is a multifunctional, USB-rechargeable LED clip light from the Compact series, ideal for hands-free illumination in automotive repair, workshops, and DIY tasks. With 14 white LEDs for front lighting up to 400 lumens and 9 red LEDs for area lighting, it supports 4-way use (clip, head, cap, lantern) via a side switch, motion sensor for touchless operation, and stepless dimming for adjustable brightness. IP54-rated for dust/drip resistance and 1m drop-proof, it's compact and versatile with a dedicated case for storage.

Key Performance Specifications

• Brightness (approx.):
  • Front Light: 400 lm (strong) / 8 lm (weak)
  • Area Light: 260 lm (white strong) / 11 lm (white weak) / 18 lm (red)
• Light Intensity (approx.):
  • Front Light: 3722 cd (max)
  • Area Light: 86 cd (white max) / 8 cd (red)
• Runtime (approx.):
  • Front Light: 5.5 h (strong) / 58 h (weak)
  • Area Light: 4.5 h (white strong) / 37 h (white weak) / 9 h (red)
• Beam Angle: Fixed wide beam
• Irradiation Distance: 122 m (max)
• Light Sources: 14 × high-brightness chip-type white LEDs, 9 × high-brightness chip-type red LEDs

Physical and Environmental Specifications

• Dimensions (W × H × D): 52.0 × 36.0 × 60.0 mm (2.05 × 1.42 × 2.36 in)
• Weight: 60 g (2.1 oz)
• Battery: Built-in Li-poly 3.7V 1200 mAh; ~300 charge cycles; 3 h charge time via USB Type-C
• IP Rating: IP54 (dustproof and drip-proof)
• Drop Durability: 1 m
• Operating Temperature: Suitable for indoor/outdoor use (no specific range listed)

Key Features

• Design: Multifunctional 4-way use (clip/head/cap/lantern); retractable clip and adjustable headband
• Controls: Side-push switch for modes; motion sensor (wave hand to toggle on/off); stepless dimming (hold switch, excluding red); instant-off (one press after delay); mode memory
• Mounting: Anti-slip headband (25 mm width); double hook carabiner for cap/clip attachment
• Additional Functions: Battery indicator (3 levels); charging indicator (3 levels); red LED for low-light hand illumination
• Applications: Automotive diagnostics, general task lighting, inspections, and portable emergencies
• Standards Compliance: RoHS compliant
