EDGE-1S 3/4" Sq Dr Torque Wrench, 1257 Ft-Lbs

HYTORC EDGE-1S is a square drive hydraulic torque wrench from the EDGE S series, engineered for precise high-torque bolting in demanding industrial environments like construction, maintenance, and petrochemical operations. This 3/4" square drive model provides up to 1,257 ft-lbs of torque with ±3% accuracy, powered by a hydraulic pump system up to 10,000 PSI for reliable efficiency. Featuring a three-moving-part ratchet design, 360° x 180° uniswivel hose connection, and removable square drive for torque/loosen modes, it's built for simple, durable performance with minimal maintenance.

Key Performance Specifications

• Torque Range: 178–1,257 ft-lbs (241–1,703 Nm)
• Accuracy: ±3%
• Drive Size: 3/4" square
• Max Operating Pressure: 10,000 PSI (690 bar)

Physical and Environmental Specifications

• Weight: 4.0 lbs (1.8 kg)
• Dimensions: Height 3.5 in (90 mm); Length 4.9 in (125 mm); Width 2.0 in (50 mm); Radius 1.0 in (25 mm)
• Operating Temperature: -4°F to 140°F (-20°C to 60°C)

Key Features

• Three-Moving-Part Ratchet Design: Fine-toothed gear mechanism minimizes wear for reliable, repeatable torque with easy maintenance
• 360° x 180° Uniswivel Hose Connection: Provides unmatched flexibility and reduces tangled hoses for safe, convenient access
• Removable Square Drive: Quick-release for switching between torque and loosen modes without additional tools
• Rear-Attached Reaction Arm: Standard arm compatible with EDGE S series; options include reaction sleeves and ALCO arms for versatile positioning
• Adjustable Side Safety Handle: Ergonomic grip for better control and reduced operator fatigue
• Corrosion-Resistant Construction: Durable housing for longevity in harsh conditions
• Low Vibration: Minimizes hand-arm vibration syndrome (HAVS) risk compared to impact tools
• Ergonomic Design: Lightweight aluminum components with three-part structure for simple operation by all skill levels
• Data Management: Pressure-to-torque conversion charts for precise control; integrable with digital gauges
• Applications: Compatible with sockets, extensions, HYTORC Washer/Nut Drivers; ideal for general maintenance bolting on flanges and pipelines
