EZDCC168SS Double Chain Clamp 10" - 168" Stainless Steel

Mathey Dearman EZDCC168SS Double Chain Clamp (D251-1014FSS) is an extra heavy-duty alignment and reforming tool designed for precise pipe fit-up in welding, fabrication, and industrial piping applications. This stainless steel version features corrosion-resistant stainless steel chain and contact points to enable contamination-free welding of exotic materials, constructed from robust heavy-duty steel with independent pivoting jackscrew pads. It ensures accurate alignment and reforming of pipes and vessels up to 20 ft (6 m) long with Schedule 80 wall thickness, handling out-of-round conditions while keeping all areas accessible for welding.

• Model Number: EZDCC168SS (D251-1014FSS)
• Product Type: Double Chain Pipe Alignment Clamp (Stainless Steel)
• Color: Silver
• Material: Stainless steel chain and contact points; heavy-duty steel body
• Clamping Range: 10" - 168" / 254 mm - 4267 mm
• Reforms Pipe To Schedule: 80 / Aligns 160
• Capacity: Pipes and vessels up to 20 ft (6 m) long; Schedule 80 wall thickness (aligns any wall schedule)
• Number of Jackbars: 48 (extra heavy-duty, independent with pivoting feet)
• Number of Main Blocks: 2 (double main block for added strength)
• Weight (Shipping): 810 lbs / 367 kg
• Overview: Extra heavy-duty double-chain clamp for aligning and reforming pipes, elbows, tees, flanges, and fittings; covers range of multiple cage clamps; ideal for fabrication shops, construction sites, and maintenance operations handling exotic materials
• Key Features:
  • Precision alignment: Double jackbars provide accurate reforming within 0.5 mm for internal/external diameters on both sides of the weld joint
  • Versatile fit-up: Handles pipes up to 20 ft (6 m) long, elbows, tees, and fittings that cage clamps cannot; one clamp covers eight cage clamp ranges
  • Quick setup: Easy chain attachment with double chain lock devices and jackscrew adjustments for rapid deployment
  • Accessibility: High-rise jackbars allow full welding access without removal
  • Durability: Fully corrosion-resistant stainless steel components withstand harsh environments and arduous reforming on thick walls
  • Safety: Includes cable hoist for secure support; reduces misalignment risks for enhanced weld quality and operator efficiency
• Packaging: 1 Clamp per Unit; Includes chain, extra heavy-duty jackbars, main blocks, two fine adjustments, cable hoist, jackscrew wrench, operating instructions; Supplied in wooden storage crate (may require forklift unloading)
• Storage: Cool, dry place away from moisture and extremes; indefinite shelf life under proper conditions
• Compliance: Meets industry standards for welding alignment and reforming tools (e.g., ASME equivalents)
