EZDCC36SS Double Chain Clamp 10" - 36" Stainless Steel

Mathey Dearman EZDCC36SS Double Chain Clamp (D251-1036SS) is a heavy-duty alignment and reforming tool designed for precise pipe fit-up in welding, fabrication, and industrial piping applications. This stainless steel version features corrosion-resistant stainless steel chain and contact points to enable contamination-free welding of exotic materials, constructed from robust heavy-duty steel with independent pivoting jackscrew pads. It ensures accurate alignment and reforming for Schedule 80 pipes from 10" to 36" (254 mm to 914 mm) up to 20 ft (6 m) long, handling elbows, tees, flanges, end caps, and fittings while keeping all areas accessible for welding.

• Model Number: EZDCC36SS (D251-1036SS)
• Product Type: Double Chain Pipe Alignment Clamp (Stainless Steel)
• Color: Silver
• Material: Stainless steel chain and contact points; heavy-duty steel body
• Clamping Range: 10" - 36" / 254 mm - 914 mm
• Reforms Pipe To Schedule: Up to 80 (45,000 PSI tensile strength)
• Capacity: Pipes and vessels up to 20 ft (6 m) long; Schedule 80 wall thickness (aligns any wall schedule)
• Number of Jackbars: 9 (extra heavy-duty, independent with pivoting feet)
• Number of Main Blocks: 1 (double chain main block with 2 fine adjustments)
• Weight (Net): Approximately 220 lbs / 100 kg
• Overview: Heavy-duty double-chain clamp for aligning and reforming pipes, elbows, tees, flanges, and fittings; covers a wide range of sizes; ideal for fabrication shops, construction sites, and maintenance operations handling exotic materials
• Key Features:
  • Precision alignment: Jackbars provide accurate reforming within 0.5 mm for internal/external diameters on both sides of the weld joint
  • Versatile fit-up: Handles pipes, elbows, tees, and fittings; one clamp covers multiple smaller clamp ranges
  • Quick setup: Easy chain attachment with double chain lock devices and jackscrew adjustments for rapid deployment
  • Accessibility: High-rise jackbars allow full welding access without removal
  • Durability: Fully corrosion-resistant stainless steel components withstand harsh environments and arduous reforming on thick walls
  • Safety: Level and support device secures fittings; reduces misalignment risks for enhanced weld quality and operator efficiency
• Packaging: 1 Clamp per Unit; Includes 2 high-strength leaf chains, 9 extra heavy-duty jackbars, main block, level and support device, jackscrew breaker bar with socket, parts and operating manual; Supplied in durable storage case
• Storage: Cool, dry place away from moisture and extremes; indefinite shelf life under proper conditions
• Compliance: Meets industry standards for welding alignment and reforming tools (e.g., ASME equivalents)
