RC102 101 kN Capacity, 54 mm Stroke, General Purpose Hydraulic Cylinder

Enerpac RC102 is a robust single-acting, spring-return hydraulic cylinder engineered for high-capacity lifting and pushing tasks in industrial maintenance, construction, and general-purpose applications. Offering an 11.2-ton (101 kN) capacity over a 54 mm stroke, this alloy steel model operates at up to 10,000 psi with features like a grooved plunger for saddle mounting, relief valves for safety, and a corrosion-resistant baked enamel finish, ensuring durability and efficiency in demanding environments.

• Product Overview
  • Name: Enerpac RC102 General Purpose Hydraulic Cylinder
  • Type: Single-acting, spring-return solid plunger cylinder
  • Primary Applications: Industrial lifting, pushing, bolting, and maintenance tasks
  • Force Output: 11.2 tons (101 kN)
  • Stroke: 54 mm (2.13 in)
  • Retraction Mechanism: Spring return
  • Operating Pressure: Maximum 10,000 psi (700 bar)
  • Collapsed Height: 121 mm (4.78 in)
• Technical Specifications
  • Capacity: 11.2 tons (101 kN)
  • Maximum Operating Pressure: 10,000 psi (700 bar)
  • Stroke: 54 mm (2.13 in)
  • Collapsed Height (A): 121 mm (4.78 in)
  • Extended Height (B): 176 mm (6.91 in)
  • Outside Diameter (D): 57 mm (2.25 in)
  • Bore Diameter (E): 43 mm (1.69 in)
  • Plunger Diameter (F): 38 mm (1.50 in)
  • Effective Area (Advance): 14.5 cm² (2.25 in²)
  • Oil Capacity (Advance): 78 cm³ (4.76 in³)
  • Weight: 4.5 kg (9.9 lbs)
  • Saddle Diameter (J): 35 mm (1.38 in)
  • Saddle Protrusion from Plunger (K): 9 mm (0.35 in)
  • Collar Thread (W): 2 3/4"-16 UN
  • Collar Thread Length (X): 30 mm (1.19 in)
  • Series: RC Series General Purpose Cylinders
• Key Features
  • Single-acting design with spring return for efficient and controlled operation
  • Alloy steel construction for superior strength and longevity
  • Unique GR2 bearing design reduces wear and extends life
  • Base mounting holes enable easy fixturing
  • Designed for use in all positions
  • Heavy-duty, pre-tensioned spring improves retraction speed
  • Grooved plunger allows for easy mounting of tilt saddles without additional hardware
  • Built-in relief valves prevent over-pressurization for enhanced safety
  • Baked enamel finish provides corrosion resistance in harsh conditions
  • Chrome-plated plunger ensures smooth action and reduced wear
  • Includes CR-400 coupler and dust cap for immediate compatibility and protection
  • Plunger wiper minimizes contamination to extend service life
