RT1817 166 kN Capacity, 435 mm Stroke, Multi-stage, Telescopic Hydraulic Cylinder

Enerpac RT1817 is a robust, 3-stage telescopic hydraulic cylinder optimized for delivering extended strokes in space-constrained environments, perfect for demanding industrial lifting, pushing, and positioning operations. Offering a maximum capacity of 19 tons (166 kN) across its 435 mm stroke, this single-acting cylinder withstands up to 10,000 psi while incorporating advanced nitrocarburized treatments for exceptional corrosion resistance and load-handling in severe conditions, ensuring reliable, synchronized performance.

• Product Overview
  • Name: Enerpac RT1817 Multi-stage Telescopic Hydraulic Cylinder
  • Type: Single-acting, 3-stage telescopic cylinder for heavy-duty applications
  • Primary Applications: Industrial lifting, pushing, and positioning tasks in construction, maintenance, and confined spaces
  • Force Output: 19 tons (166 kN) at maximum stroke
  • Stroke: 435 mm (17.13 in) total
  • Stages: 3 stages, each with 145 mm (5.71 in) stroke
  • Operating Pressure: Maximum 10,000 psi (700 bar)
  • Collapsed Height: 345 mm (13.58 in) minimum
• Technical Specifications
  • Capacity (Stage 1): 104 tons (925 kN)
  • Capacity (Stage 2): 45 tons (400 kN)
  • Capacity (Stage 3): 19 tons (166 kN)
  • Maximum Operating Pressure: 10,000 psi (700 bar)
  • Total Stroke: 435 mm (17.13 in)
  • Collapsed Height (A): 345 mm (13.58 in)
  • Extended Height: 780 mm (30.71 in)
  • Oil Capacity (Advance): 3,092 cm³ (188.7 in³)
  • Weight: 42 kg (92.6 lbs)
  • Outside Diameter (D): 170 mm (6.69 in)
  • Base to Advance Port (H): 27 mm (1.06 in)
  • Saddle Diameter (J): 80 mm (3.15 in)
  • Body Material: Steel with nitrocarburized surface treatment
  • Side-Load Capacity: 3% of full capacity
  • Series: RT Series Telescopic Cylinders
• Key Features
  • Enables long strokes in confined spaces for efficient load handling
  • Nitrocarburized treatment inside and out for corrosion protection and harsh-condition durability
  • Hardened surfaces resist side-loading and cyclic wear
  • Triple wear bearings support stable lifting stages
  • Integrated tilting saddle allows up to 5 degrees of tilt
  • Synchronized multi-stage extension for precise control
  • Lifting eyes for safer handling and positioning
