RT3323, 309 kN Capacity, 600 mm Stroke, Multi-stage, Telescopic Hydraulic Cylinder

Enerpac RT3323 is a robust, 3-stage telescopic hydraulic cylinder optimized for delivering extended strokes in space-constrained environments, perfect for demanding industrial lifting, pushing, and positioning operations. Offering a maximum capacity of 35 tons (309 kN) across its 600 mm stroke, this single-acting cylinder withstands up to 10,000 psi while incorporating advanced nitrocarburized treatments for exceptional corrosion resistance and load-handling in severe conditions, ensuring reliable, synchronized performance.

• Product Overview
  • Name: Enerpac RT3323 Multi-stage Telescopic Hydraulic Cylinder
  • Type: Single-acting, 3-stage telescopic cylinder for heavy-duty applications
  • Primary Applications: Industrial lifting, pushing, and positioning tasks in construction, maintenance, and confined spaces
  • Force Output: 35 tons (309 kN) at maximum stroke
  • Stroke: 600 mm (23.62 in) total
  • Stages: 3 stages, each with 200 mm (7.87 in) stroke
  • Operating Pressure: Maximum 10,000 psi (700 bar)
  • Collapsed Height: 476 mm (18.74 in) minimum
• Technical Specifications
  • Capacity (Stage 1): 223 tons (1,984 kN)
  • Capacity (Stage 2): 89 tons (792 kN)
  • Capacity (Stage 3): 35 tons (309 kN)
  • Maximum Operating Pressure: 10,000 psi (700 bar)
  • Total Stroke: 600 mm (23.62 in)
  • Collapsed Height (A): 476 mm (18.74 in)
  • Extended Height: 1,076 mm (42.36 in)
  • Oil Capacity (Advance): 538 in³ (8.82 L)
  • Weight: 122 kg (269 lbs)
  • Body Material: Steel with nitrocarburized surface treatment
  • Side-Load Capacity: 3% of full capacity
  • Series: RT Series Telescopic Cylinders
• Key Features
  • Enables long strokes in confined spaces for efficient load handling
  • Nitrocarburized treatment inside and out for corrosion protection and harsh-condition durability
  • Hardened surfaces resist side-loading and cyclic wear
  • Double or triple wear bearings support stable lifting stages
  • Integrated tilting saddle allows up to 5 degrees of tilt
  • Synchronized multi-stage extension for precise control
