NTD15CN Preset Torque Screwdriver, 5-15 cN.m

Type: Preset Non-Rotary Click Type Torque Screwdriver

Torque Range:

• S.I.: 5–15 cN·m
• Metric: 0.5–1.5 kgf·cm
• American: 0.5–1.3 lbf·in

Accuracy: ±3% of the set torque value

Drive Size: 1/4" Hex (6.35 mm, accepts standard E 6.3 hex bits, sold separately)

Applicable Screws:

• Small Screw: M1.8
• Tapping Screw: M1.4–M1.6

Dimensions:

• Overall Length (L'): 94 mm
• Grip Diameter (D1): 19.5 mm
• Body Diameter (D4): 11 mm
• L1: 24 mm
• L2: 59 mm

Weight: 0.07 kg

Adjusting Tool: Requires Tohnichi #42 Adjusting Tool (sold separately) for torque setting

Features:

• Preset torque mechanism with no external scale, ensuring tamper-proof settings.
• Non-rotary slip mechanism: Provides a “click” and slight spring-back to signal torque achievement; additional torque may be applied if turning continues, unlike rotary slip models (e.g., RNTD).
• Enhanced reliability and durability with Tohnichi’s toggle clutch torque mechanism.
• Compact and lightweight design for precision tasks in confined spaces.
• Clockwise operation only (counterclockwise tightening model available upon request).
• Meets ISO 6789 Type II Class E standards for global use.

Applications: Ideal for repetitive tightening tasks in mass production and maintenance, especially for small screws in electronics or precision assembly.

Notes:

• Requires a torque tester (e.g., TDT3/TDT3-G, TCC2/TCC2-G) for setting the preset torque.
• Standard bits are not included; compatible with commercially available 1/4" hex bits.
