P392FP Two Speed, Lightweight Hydraulic Foot Pump, 492 cm3 Usable Oil

Enerpac P392FP Two Speed Lightweight Hydraulic Foot Pump 492 cm3 Usable Oil is a compact, foot-operated hydraulic pump designed for reliable, hands-free operation in industrial maintenance and assembly tasks requiring single-acting cylinder control. Featuring two-speed technology for rapid low-pressure advance and high-pressure efficiency up to 10,000 psi, this lightweight tool includes a 3-way 3-position treadle valve operable by hand or foot for advance/hold/retract functions, 492 cm³ (30 in³) usable oil reservoir in durable aluminum construction, and ergonomic steel lever pedal for fatigue-free operation, ensuring precise performance without external power sources in demanding environments.

• Model Number: P392FP
• Product Type: Lightweight Hydraulic Foot Pump (Two-Speed, 3/3 Treadle Valve)
• Color: Silver/Gray
• Material: Aluminum Reservoir with Steel Frame and Hardened Components
• Capacity: 10,000 psi (700 bar) Maximum Operating Pressure
• Oil Capacity: 492 cm³ (30 in³) Usable
• Valve Type: 3-Way, 3-Position Treadle (Hand/Foot Operated: Advance/Hold/Retract)
• Flow Rate: 0.15 in³/stroke (2.46 cm³/stroke) at 10,000 psi
• Weight (Net): 8.5 kg / 18.8 lbs
• Dimensions: Length: 533 mm (21"), Width: 102 mm (4"), Height: 178 mm (7")
• Overview: Compact two-speed foot pump for efficient single-acting applications; ideal for field or workshop use with lightweight design, high-pressure capability, and hands-free treadle control for precise positioning
• Key Features:
  • Two-speed operation enables quick initial advance at low pressure for faster setup, switching to high force for controlled operation up to 10,000 psi
  • Treadle valve operable by hand or foot provides ergonomic, hands-free control to reduce bending and fatigue
  • Durable aluminum reservoir with steel frame resists corrosion and damage, with sight glass for easy oil level monitoring
  • Internal pressure relief valve provides overload protection, factory-set for safety
  • Compatible with Enerpac RC-series single-acting cylinders and standard hydraulic hoses for versatile industrial tasks
