RC1006 933 kN Capacity, 168 mm Stroke, General Purpose Hydraulic Cylinder

Enerpac RC1006 is a robust single-acting, spring-return hydraulic cylinder engineered for high-capacity lifting and pushing tasks in industrial maintenance, construction, and general-purpose applications. Offering a 103-ton (933 kN) capacity over a 168 mm stroke, this alloy steel model operates at up to 10,000 psi with features like a grooved plunger for saddle mounting, relief valves for safety, and a corrosion-resistant baked enamel finish, ensuring durability and efficiency in demanding environments.

• Product Overview
  • Name: Enerpac RC1006 General Purpose Hydraulic Cylinder
  • Type: Single-acting, spring-return solid plunger cylinder
  • Primary Applications: Industrial lifting, pushing, bolting, and maintenance tasks
  • Force Output: 103 tons (933 kN)
  • Stroke: 168 mm (6.63 in)
  • Retraction Mechanism: Spring return
  • Operating Pressure: Maximum 10,000 psi (700 bar)
  • Collapsed Height: 357 mm (14.06 in)
• Technical Specifications
  • Capacity: 103 tons (933 kN)
  • Maximum Operating Pressure: 10,000 psi (700 bar)
  • Stroke: 168 mm (6.63 in)
  • Collapsed Height (A): 357 mm (14.06 in)
  • Extended Height (B): 525 mm (20.69 in)
  • Outside Diameter (D): 178 mm (7 in)
  • Bore Diameter (E): 130 mm (5.13 in)
  • Plunger Diameter (F): 95 mm (3.75 in)
  • Effective Area (Advance): 133 cm² (20.65 in²)
  • Oil Capacity (Advance): 2,244 cm³ (136.93 in³)
  • Weight: 61.2 kg (135 lbs)
  • Series: RC Series General Purpose Cylinders
• Key Features
  • Single-acting design with spring return for efficient and controlled operation
  • Alloy steel construction for superior strength and longevity
  • Grooved plunger allows for easy mounting of tilt saddles without additional hardware
  • Built-in relief valves prevent over-pressurization for enhanced safety
  • Baked enamel finish provides corrosion resistance in harsh conditions
  • Chrome-plated plunger ensures smooth action and reduced wear
  • Includes CR-400 coupler and dust cap for immediate compatibility and protection
  • Plunger wiper minimizes contamination to extend service life
