RC1514 142 kN Capacity, 356 mm Stroke, General Purpose Hydraulic Cylinder

Enerpac RC1514 is a robust single-acting, spring-return hydraulic cylinder from the RC-TRIO series, engineered for high-capacity lifting and pushing tasks in industrial maintenance, construction, and general-purpose applications. Offering a 15.7-ton (142 kN) capacity over a 356 mm stroke, this alloy steel model operates at up to 10,000 psi with advanced features like a TRIO bearing system for enhanced side-load resistance, hybrid pre-tensioned springs for up to 3x faster retraction, relief valves for safety, and a corrosion-resistant baked enamel finish, ensuring superior durability and productivity in demanding environments.

• Product Overview
  • Name: Enerpac RC1514 General Purpose Hydraulic Cylinder
  • Type: Single-acting, spring-return solid plunger cylinder (RC-TRIO series)
  • Primary Applications: Industrial lifting, pushing, bolting, and maintenance tasks
  • Force Output: 15.7 tons (142 kN)
  • Stroke: 356 mm (14.00 in)
  • Retraction Mechanism: Spring return
  • Operating Pressure: Maximum 10,000 psi (700 bar)
  • Collapsed Height: 475 mm (18.69 in)
• Technical Specifications
  • Capacity: 15.7 tons (142 kN)
  • Maximum Operating Pressure: 10,000 psi (700 bar)
  • Stroke: 356 mm (14.00 in)
  • Collapsed Height (A): 475 mm (18.69 in)
  • Extended Height (B): 830 mm (32.69 in)
  • Outside Diameter (D): 70 mm (2.75 in)
  • Bore Diameter (E): 50.8 mm (2.00 in)
  • Plunger Diameter (F): 41.3 mm (1.63 in)
  • Effective Area (Advance): 20.3 cm² (3.14 in²)
  • Oil Capacity (Advance): 721 cm³ (43.98 in³)
  • Weight: 11.8 kg (26 lbs)
  • Series: RC Series General Purpose Cylinders
• Key Features
  • Single-acting design with hybrid pre-tensioned return springs for up to 3x faster retraction and increased productivity
  • TRIO bearing system with hardened composite wear bands for greater side-load resistance and extended cylinder life
  • High-strength steel plunger with nickel plating for improved durability, corrosion protection, and side-load handling
  • Built-in relief valves prevent over-pressurization for enhanced safety
  • Grooved plunger and internal threads allow easy mounting of tilt saddles and tools without additional hardware
  • Baked enamel finish provides superior corrosion resistance in harsh conditions
  • Chrome-plated plunger ensures smooth action and reduced wear
  • Plunger wiper and durable seals minimize contamination to extend service life
  • Includes CR-400 coupler and dust cap for immediate compatibility and protection
  • Collar threads and base mounting holes enable easy fixturing
