XA11VG, Air Driven Hydraulic Foot Pump, 4/3 Valve, 1,0 litres Usable Oil, Integrated Pressure Gauge, For use with Double-Acting Cylinder or Tool

Enerpac XA11VG Air Driven Hydraulic Foot Pump 4/3 Valve 1.0 Litres Usable Oil Integrated Pressure Gauge For use with Double-Acting Cylinder or Tool is a high-efficiency, air-powered hydraulic pump designed for reliable, foot-actuated operation in industrial maintenance and assembly tasks requiring double-acting cylinder control. Featuring Z-Class two-speed technology for rapid low-pressure advance and high-pressure efficiency up to 10,000 psi, this pump includes a 4-way 3-position manual valve with advance/hold/retract functions, 1.0 L usable oil reservoir, integrated pressure gauge for real-time monitoring, and operates on compressed air (30-125 psi) for portable, explosion-proof performance in hazardous environments, ensuring fast cycle times and consistent power delivery without electrical hazards.

• Model Number: XA11VG
• Product Type: Air Driven Hydraulic Foot Pump (Two-Speed, 4/3 Manual Valve)
• Color: Silver/Gray
• Material: Steel Reservoir with Aluminum Housing and Hardened Components
• Capacity: 10,000 psi (700 bar) Maximum Operating Pressure
• Oil Capacity: 1.0 L (61 in³) Usable / 1.88 L (115 in³) Total Reservoir
• Valve Type: 4-Way, 3-Position Manual (Advance/Hold/Return)
• Flow Rate: 15 in³/min (0.25 L/min) at 10,000 psi; 120 in³/min (2.0 L/min) No Load
• Air Consumption: 10-35 SCFM
• Air Pressure Range: 30-125 psi
• Sound Level: 94-97 dBa
• Weight (Net): 11.7 kg / 25.8 lbs
• Dimensions: Length: 508 mm (20"), Width: 508 mm (20"), Height: 203 mm (8")
• Overview: High-flow air hydraulic foot pump with two-speed operation for efficient double-acting cylinder use; ideal for remote or hazardous sites with air power, providing rapid cycles and Z-Class reliability for maintenance tasks
• Key Features:
  • Foot-actuated design reduces operator fatigue with ergonomic control for precise valve operation in demanding environments
  • Integrated pressure gauge allows real-time monitoring up to 10,000 psi for safe, accurate force application
  • Two-speed pump delivers high initial flow for quick advance, transitioning to sustained power for efficient productivity
  • Explosion-proof air drive suitable for hazardous locations, with low noise and vibration for extended use
  • Compatible with Enerpac RC-series double-acting cylinders and tools for versatile industrial applications
